DC combiner box 12 in and 1 out
  • DC combiner box 12 in and 1 outDC combiner box 12 in and 1 out

DC combiner box 12 in and 1 out

CNLonQcom is a Chinese factory specializing in the production of DC combiner box 12 in and 1 out. We provide users with safer, simpler, more aesthetically pleasing, and applicable photovoltaic system products.

Model:LQX F12/1 DC

Send Inquiry

Product Description

The DC combiner box 12 in and 1 out offers features such as dust-proof, anti-reverse, moisture-proof, and intelligent monitoring, with excellent impact resistance and stability.
Please refer to the parameter table and images for detailed specifications.

1.The DC combiner box 12 in and 1 out simplifies the physical wiring between solar panels and inverters.
2.The specification of the DC combiner box 12 in and 1 out


Name LQX F12/1 DC

Electric parameter
System maximum dc voltage 1000 1500
Maximum input current for each string 15A
Maximum input strings 12
Maximum output switch current 200A
Number of inverter MPPT N
Number of Output strings 1

Lightning protection
Category of test II grade protection
Nominal discharge current 20kA
Maximum discharge current 40kA
Voltage protection level 3.6kV 5.3kV
Maximum continuous operating voltage Uc  1050V 1500V
Poles 3P
Structure characteristic Plug-push module

Protection grade IP66
Output switch DC isolation switch(standard)/DC circuit breaker(optional)
SMC4 Waterproof Connectors  Standard
PV dc fuse Standard
PV surge protector Standard
Monitoring module Optional
Preventing diode Optional
Box material PVC
Installation method Wall mounting type
Operating Temperature -25℃ ~+55℃
Elevation of temperature 2km
Permissible relative humidity 0-95%,noondensation



The details of the DC combiner box 12 in and 1 out


Q1: When can I get the pricing?
A1: Typically, we will provide a quotation within 24 hours upon receiving your inquiry.

Q2: What are the accepted payment terms?
A2: We accept credit cards, Western Union transfers, PayPal, or bank transfers.

Q3: Can I get free samples?
A3: Yes, you can. The buyer is responsible for the shipping cost, but the samples themselves are free.

Q4: Can I customize the product?
A4: CNLonQcom is a Chinese factory specialized in producing DC combiner box 12 in and 1 out. We welcome OEM and ODM requests and can provide various customized solutions to meet your needs.

Q5: After placing an order, how long does it take for delivery?
A5: The production cycle for delivery is determined based on the specific quantity of products ordered, generally ranging from 15 to 30 days.
